ZX80-B-5P datasheet pdf and USB, DVI, HDMI Connectors product details from Hirose Electric Co Ltd stock available on our website
SOT-23
ZX80-B-5P Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
26 Weeks
Contact Material
Copper
Mount
Surface Mount, Through Hole, Vertical
Mounting Type
Surface Mount, Through Hole
Mounting Feature
Vertical
Shell/Shielding Material
Steel, Stainless
Operating Temperature
-30°C~85°C
Packaging
Tray
Series
ZX
Published
2007
Feature
Pick and Place
Part Status
Obsolete
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Termination
Solder
Connector Type
USB - micro B
Gender
Receptacle
Voltage - Rated
30VAC
Current Rating (Amps)
1.8A
Orientation
Right Angle
Shielding
Shielded
Current Rating
1A
Insulation Color
Black
Contact Finish
Gold
Number of Contacts
5
Number of Ports
1
Mating Cycles
10000
Specifications
USB 2.0
USB
USB 2.0
Material Flammability Rating
UL94 V-0
REACH SVHC
No SVHC
Radiation Hardening
No
RoHS Status
RoHS Compliant
Lead Free
Lead Free
In-Stock:2246 items
ZX80-B-5P Product Details
The Hirose ZX80-B-5P is a USB 2.0 Micro B receptacle connector designed for use in a variety of applications. It features a 5-position SMD (surface mount device) design, allowing for easy installation and a secure connection. The connector is rated for up to 5A of current and is compatible with USB 2.0, DVI, and HDMI standards. It is ideal for use in consumer electronics, automotive, and industrial applications.
Features of the Hirose ZX80-B-5P include:
• 5-position SMD design for easy installation and secure connection • Rated for up to 5A of current • Compatible with USB 2.0, DVI, and HDMI standards • Ideal for consumer electronics, automotive, and industrial applications
Applications of the Hirose ZX80-B-5P include:
• Connecting USB 2.0 devices • Connecting DVI and HDMI devices • Connecting consumer electronics, automotive, and industrial devices • Connecting audio and video devices
