Name: DF50-20DP-1H(51)
Brand: Hirose Electric Co Ltd
SKU: DF50-20DP-1H(51)
Price: 1.35000 USD
Availability: InStock

new-10%

DF50-20DP-1H(51)

Manufacturer part number:DF50-20DP-1H(51)

Manufacturer:Hirose Electric Co Ltd

Description:DF50-20DP-1H(51) datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:DF50-20DP-1H(51) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Brass
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Insulation Material	Polyester
Housing Material	Polymer
Operating Temperature	-35°C~85°C
Packaging	Tape & Reel (TR)
Published	2013
Series	DF50
Feature	Solder Retention
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header
Number of Positions	20
Number of Rows	2
Voltage - Rated	100V
HTS Code	8536.69.40.40
Fastening Type	Latch Lock
Contact Finish - Mating	Gold
Contact Type	Male Blade
Total Number of Contacts	20
Orientation	Right Angle
Terminal Pitch	0.9906mm
Insulation Height	0.354 9.00mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Current Rating	1A
Pitch - Mating	0.039 1.00mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Shrouding	Shrouded - 4 Wall
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Contact Gender	Male
Rated Current (Signal)	1A
Contact Resistance	30mOhm
Insulation Resistance	500MOhm
Mating Contact Pitch	0.039 inch
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	300VAC V
PCB Contact Row Spacing	5.6896 mm
Durability	30 Cycles
Contact Finish Thickness - Mating	2.00μin 0.051μm
Contact Finish Thickness - Post	2.00μin 0.051μm
Material Flammability Rating	UL94 V-0
REACH SVHC	Unknown
RoHS Status	RoHS Compliant
Lead Free	Lead Free

DF50-20DP-1H(51) Product Details

DF50-20DP-1H(51) Overview

You get it in Header packaging.Surface Mount, Right Angle indicates that the device is mounted.It's packaged in a Tape & Reel (TR) case.The product is a part of the DF50 Series.Many aspects of its Solder Retention feature increase its effectiveness.It is mounted by Surface Mount.As a result, the device runs at -35°C~85°C Operating Temperature.
