Name: DF19-30S-1C
Brand: Hirose Electric Co Ltd
SKU: DF19-30S-1C
Price: 0.77000 USD
Availability: InStock

new-10%

DF19-30S-1C

Manufacturer part number:DF19-30S-1C

Manufacturer:Hirose Electric Co Ltd

Description:1 Rows Plug Bulk Beige 30 Positions Free Hanging (In-Line) Female Socket Crimp DF19 Polyamide

Case Package:SOT-23

Datasheet:DF19-30S-1C Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Contact Material	Bronze
Contact Plating	Gold
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide
Packaging	Bulk
Series	DF19
Published	2008
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Number of Positions	30
Max Operating Temperature	85°C
Min Operating Temperature	-35°C
Color	Beige
Number of Rows	1
Voltage - Rated	100V
Additional Feature	LOW PROFILE
HTS Code	8536.69.40.40
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Female Socket
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.039 1.00mm
Total Number of Contacts	30
Orientation	Straight
Reference Standard	UL
Reliability	COMMERCIAL
Lead Pitch	1mm
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Body Breadth	0.059 inch
Contact Gender	Male
UL Flammability Code	94V-0
Housing Color	Grey
Body Depth	0.24 inch
Insulation Resistance	500MOhm
Note	Contacts Not Included
Polarization Key	POLARIZED HOUSING
Durability	50 Cycles
Insertion Force-Max	3.0024 N
Contact Termination	Crimp
Wire Size (Min)	32 AWG
Wire Size (Max)	28 AWG
Radiation Hardening	No
RoHS Status	RoHS Compliant
Lead Free	Lead Free

DF19-30S-1C Product Details

DF19-30S-1C Overview

Packaging is Plug.Free Hanging (In-Line) is the mounting type.Packaging for the product is carried out via a Bulk case.As a product of the DF19 Series, it can be found in this category.There are also other features such as LOW PROFILE, to name only a few.In this case, Free Hanging mounts the part.
