Name: DF11GZ-18DP-2V(20)
Brand: Hirose Electric Co Ltd
SKU: DF11GZ-18DP-2V(20)
Price: 1.59000 USD
Availability: InStock

new-10%

DF11GZ-18DP-2V(20)

Manufacturer part number:DF11GZ-18DP-2V(20)

Manufacturer:Hirose Electric Co Ltd

Description:DF11 Series 2-Row Header Solder Brass Tube Surface Mount Tin Polyamide (PA), Nylon 18-Position Board to Board or Cable 0.283 7.19mm Height

Case Package:SOT-23

Datasheet:DF11GZ-18DP-2V(20) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Brass
Mount	Surface Mount
Mounting Type	Surface Mount
Contact Shape	Circular
Insulation Material	Polyamide (PA), Nylon
Housing Material	Plastic
Operating Temperature	-30°C~85°C
Packaging	Tube
Series	DF11
Published	2010
JESD-609 Code	e3
Feature	Board Guide, Solder Retention
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	18
Number of Rows	2
Gender	Male
Voltage - Rated	250V
Fastening Type	Detent Lock
Contact Finish - Mating	Tin
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Total Number of Contacts	18
Insulation Height	0.283 7.19mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Reach Compliance Code	unknown
Current Rating	2A
Pitch - Mating	0.079 2.00mm
Row Spacing - Mating	0.079 (2.00mm)
Shrouding	Shrouded - 4 Wall
Lead Pitch	2mm
UL Flammability Code	94V-0
Housing Color	Beige
Contact Finish Thickness - Mating	39.4μin 1.00μm
Stack Height (Mating)	8.2mm 8.45mm 9.55mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Lead Free	Lead Free

DF11GZ-18DP-2V(20) Product Details

DF11GZ-18DP-2V(20) Overview

Packaging is in the form of Header.This device has a Surface Mount mounting type.An orange Tube case is used to package the product.Specifically, it is one of the products in the DF11 Series.Several benefits come from the Board Guide, Solder Retention feature.There is a mounting hole at Surface Mount.Devices operate at -30°C~85°C operating temperatures.
