Name: DF11-32DP-2DSA(24)
Brand: Hirose Electric Co Ltd
SKU: DF11-32DP-2DSA(24)
Price: 1.28000 USD
Availability: InStock

new-10%

DF11-32DP-2DSA(24)

Manufacturer part number:DF11-32DP-2DSA(24)

Manufacturer:Hirose Electric Co Ltd

Description:DF11-32DP-2DSA(24) datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:DF11-32DP-2DSA(24) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Brass
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon
Housing Material	Polyamide
Operating Temperature	-30°C~85°C
Packaging	Tube
Published	2008
Series	DF11
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	32
Number of Rows	2
Voltage - Rated	250V
Fastening Type	Detent Lock
Contact Finish - Mating	Tin
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Orientation	Straight
Insulation Height	0.260 6.60mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Reach Compliance Code	unknown
Current Rating	2A
Pitch - Mating	0.079 2.00mm
Number of Conductors	ONE
Reference Standard	UL, CSA
Voltage - Rated AC	30V
Reliability	COMMERCIAL
Body Length or Diameter	1.339 inch
Row Spacing - Mating	0.079 (2.00mm)
Contact Length - Post	0.118 3.00mm
Shrouding	Shrouded - 4 Wall
Number Of PCB Rows	2
Lead Pitch	2mm
Contact Length - Mating	0.118 3.00mm
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.197 inch
Contact Gender	Male
UL Flammability Code	94V-0
Housing Color	Black
Rated Current (Signal)	2A
Overall Contact Length	0.299 7.60mm
Contact Resistance	30mOhm
Insulation Resistance	1GOhm
Mating Contact Pitch	0.079 inch
Polarization Key	GUIDE SLOT(S)
Dielectric Withstanding Voltage	650VAC V
Durability	30 Cycles
Withdrawl Force-Min	.3058 N
Contact Finish Thickness - Mating	39.4μin 1.00μm
Length - Termination	0.118 inch
Stack Height (Mating)	7.55 7.8mm 8.9mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

DF11-32DP-2DSA(24) Product Details

DF11-32DP-2DSA(24) Overview

The packaging contains Header.The device's mounting type is Through Hole.To package the product, a Tube case is used.It belongs to the DF11 Series of products.There is a mounting hole at Through Hole.Device runs at -30°C~85°C Operating Temperature.
