Name: DF11-32DEP-2C
Brand: Hirose Electric Co Ltd
SKU: DF11-32DEP-2C
Price: 0.64000 USD
Availability: InStock

new-10%

DF11-32DEP-2C

Manufacturer part number:DF11-32DEP-2C

Manufacturer:Hirose Electric Co Ltd

Description:2 Rows Plug Bulk Black 32 Positions Panel Mount, Snap-In Male Pin Crimp DF11 Polyamide

Case Package:SOT-23

Datasheet:DF11-32DEP-2C Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	NOT SPECIFIED
Mount	Panel, Snap in
Mounting Type	Panel Mount, Snap-In
Housing Material	Polyamide
Packaging	Bulk
Series	DF11
Published	2004
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Connector Type	Plug
Number of Positions	32
Max Operating Temperature	85°C
Min Operating Temperature	-30°C
Color	Black
Number of Rows	2
Voltage - Rated	250V
Additional Feature	PANEL MOUNTABLE
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	NOT SPECIFIED
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	WITH CABLE ASSEMBLY
Pitch	0.079 2.00mm
Total Number of Contacts	32
Orientation	Straight
Depth	13mm
Reach Compliance Code	unknown
Current Rating	2A
Reference Standard	UL, CSA
Reliability	COMMERCIAL
Rated Current (Signal)	2A
Contact Resistance	30mOhm
Insulation Resistance	1000000000Ohm
Row Spacing	0.079 (2.00mm)
Note	Contacts Not Included
Max Voltage Rating (AC)	250V
Max Current Rating	2A
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	650VAC V
Wire Gauge (Max)	22 AWG
Wire Gauge (Min)	26 AWG
Durability	30 Cycles
Withdrawl Force-Min	.3058 N
Contact Termination	Crimp
Contact Design	PREASSEM CONN
Wire Size (Min)	30 AWG
Length	39mm
RoHS Status	RoHS Compliant
Lead Free	Lead Free

DF11-32DEP-2C Product Details

DF11-32DEP-2C Overview

A Plug package is included with it.Its mounting type is Panel Mount, Snap-In.Packaging is performed using a Bulk case.It is part of the DF11 Series of products.Additionally, there are other features, such as PANEL MOUNTABLE.Panel, Snap in mounts the part.
