Name: 14110413002000
Brand: HARTING
SKU: 14110413002000
Price: 1.41000 USD
Availability: InStock

new-10%

14110413002000

Manufacturer part number:14110413002000

Manufacturer:HARTING

Description:14110413002000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from HARTING stock available on our website

Case Package:SOT-23

Datasheet:14110413002000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	9 Weeks
Contact Material	Copper Alloy
Mount	Panel, Surface Mount
Mounting Type	Surface Mount
Material	Glass fibre, Polymer
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-40°C~125°C
Packaging	Cut Tape (CT)
Series	har-flexicon®
Feature	Board Guide
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	SMD/SMT
ECCN Code	EAR99
Type	Header, Male Pins, Shrouded (4 Side)
Color	Black
Number of Rows	1
Gender	Male
Voltage - Rated	160V
Subcategory	Headers and Edge Type Connectors
Pitch	0.100 2.54mm
Total Number of Contacts	4
Orientation	Horizontal
Depth	5mm
Insulation Height	0.197 5.00mm
Current Rating	7.3A
Number of Conductors	ONE
Reference Standard	UL
Termination Style	Solder
Reliability	COMMERCIAL
Number Of PCB Rows	1
PCB Contact Pattern	RECTANGULAR
Contact Style	SQ PIN-SKT
Contact Resistance	20mOhm
Voltage	160V
Polarization Key	POLARIZED HOUSING
Number of Levels	1
Current	6A
Contact Pattern	RECTANGULAR
Contact Mating Finish	Tin
Header Orientation	90°, Right Angle
Number of Positions Per Level	4
Length	15.47mm
Width	7mm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant

14110413002000 Product Details

14110413002000 Overview

Surface Mount is the mounting type.It is necessary to use a Cut Tape (CT) case for packaging the product.There is a product in the har-flexicon? Series.A number of features make it more powerful because of its Board Guide feature.You've got Panel, Surface Mount mounted on the part.This device operates at a temperature of -40°C~125°C.In addition to its benefits, this part also shares many with the other products in the Header, Male Pins, Shrouded (4 Side) series.
