Name: 09652626810
Brand: HARTING
SKU: 09652626810
Price: 5.13000 USD
Availability: InStock

new-10%

09652626810

Manufacturer part number:09652626810

Manufacturer:HARTING

Description:09652626810 datasheet pdf and D-Sub Connectors product details from HARTING stock available on our website

Case Package:SOT-23

Datasheet:09652626810 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Dielectric Material	Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Housing Material	PBT
Shell Material, Finish	Steel
Operating Temperature	-55°C~125°C
Packaging	Bulk
Feature	Board Lock, Grounding Indents
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Plug, Male Pins
Number of Positions	15
Number of Rows	2
Contact Finish - Mating	NOT SPECIFIED
MIL Conformance	NO
DIN Conformance	YES
IEC Conformance	YES
Filter Feature	NO
Contact Type	Signal
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	6.5A
Total Number of Contacts	15
Mating Information	MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code	94V-0
Empty Shell	NO
Flange Feature	Housing/Shell (Unthreaded)
Connector Style	D-Sub
Contact Form	Stamped
Shell Size, Connector Layout	2 DA A
Backset Spacing	0.409 (10.40mm)
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

09652626810 Product Details

09652626810 Overview

The product comes in a package of Plug, Male Pins.This device has a mounting type of Through Hole, Right Angle.We package the product with a Bulk case.In many ways, Board Lock, Grounding Indents makes it more powerful.Mounting of the part is based on Through Hole.This device runs at -55°C~125°C operating temperature.
