Name: FR805
Brand: Diodes Incorporated
SKU: FR805
Availability: InStock

new-10%

FR805

Manufacturer part number:FR805

Manufacturer:Diodes Incorporated

Description:FR805 datasheet pdf and Diodes - Rectifiers - Single product details from Diodes Incorporated stock available on our website

Case Package:SOT-23

Datasheet:FR805 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-2
Number of Pins	2
Diode Element Material	SILICON
Packaging	Tube
Published	2001
JESD-609 Code	e3
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	175°C
Min Operating Temperature	-65°C
Additional Feature	HIGH RELIABILITY
HTS Code	8541.10.00.80
Capacitance	70pF
Subcategory	Rectifier Diodes
Voltage - Rated DC	600V
Peak Reflow Temperature (Cel)	260
Reach Compliance Code	not_compliant
Current Rating	8A
[email protected] Reflow Temperature-Max (s)	40
Pin Count	3
Qualification Status	Not Qualified
Number of Elements	1
Element Configuration	Single
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	10μA @ 600V
Output Current	8A
Voltage - Forward (Vf) (Max) @ If	1.3V @ 8A
Case Connection	CATHODE
Operating Temperature - Junction	-65°C~175°C
Forward Voltage	1.3V
Max Reverse Voltage (DC)	600V
Average Rectified Current	8A
Number of Phases	1
Reverse Recovery Time	250 ns
Peak Non-Repetitive Surge Current	150A
Reverse Current-Max	10μA
RoHS Status	ROHS3 Compliant
Lead Free	Exempt

FR805 Product Details

FR805 Overview

This device has an average rectified current of 8A volts.The fuse's current rating is 8A, which is the maximum current the fuse can handle for an indefinite time without deteriorating too much.Depending on the capacitance, the device can deliver a value of 70pF.Upon reaching maximum reverse current, it reaches 10μA.
