AP7342D-3018FS6-7 Description
The AP7342D-3018FS6-7 is a dual low dropout regulator with high output voltage accuracy, low RDSON, high PSRR, low output noise, and low quiescent current. This regulator is based on a CMOS process. Each regulator includes a voltage reference, error amplifier, current limit circuit, and an enabled input to turn on/off output. With the integrated resistor network, fixed output voltage versions can be delivered. With its low power consumption and line and load transient response, the AP7342D-3018FS6-7 is well suited for low-power handheld communication equipment.
AP7342D-3018FS6-7 Features
Low VIN and Wide VIN Range: 1.7V to 5.25V
Guarantee Output Current: 150mA
VOUT Accuracy ±1%
Ripple Rejection: 75dB at 1kHz
Low Output Noise: 60µVrms from 10Hz to 100kHz
Quiescent Current as Low as 35µA
VOUT Fixed 1.2V to 3.6V
AP7342D-3018FS6-7 Applications
Smart Phone/PAD
RF Supply
Cameras
Portable Video
Portable Media Player
Wireless Adapter
Wireless Communication
