CY2XL11ZXCT Overview
As a clock IC, PLLs is packaged using the Tape & Reel (TR) method. This clock generator is embedded in the 8-TSSOP (0.173, 4.40mm Width) package. Under reflowing process, this clock generator ic is able to sustain a maximum temperature of 260. 8 terminations can be found in frequency synthesizer. Basically, a voltage of 3.3V should be applied to this electronic frequency generator. Crystal is designed as this clock generator's input. This clock-based frequency generator provides a frequency up to 100MHz Max. This component can be conveniently installed on the panel thanks to the Surface Mount. Clock PLL works with 2.375V~3.465V supply voltage provided. The ambient temperature should be set at -5°C~70°C, which is estimated by the test statistics. This is a clock generator compatible with LVDS logic levels. This electronic component can be classified as a Clock Generator. This clock-generating IC is a 8-bit device designed explicitly for microprocessors. According to the base part number CY2XL11, its related parts can be found. There is an available 8 pin on the clock generators. RF synthesizers can handle voltages up to 3.3V. For better clock signal output, this clock PLL is featured with CAN ALSO OPERATE AT 2.5V SUPPLY. Clock PLL is facilitated with 1 signal outputs to magnify output frequency as high as possible. A supply current of 120mA needs to be provided to fully play RF synthesizer's function.
CY2XL11ZXCT Features
Available in the 8-TSSOP (0.173, 4.40mm Width)
Supply voltage of 3.3V
Operating supply voltage of 3.3V
CY2XL11ZXCT Applications
There are a lot of Cypress Semiconductor Corp
CY2XL11ZXCT Clock Generators applications.
- Instrument
- Automatic test equipment
- Wide area power system
- Digital circuits
- Wireless base station for LTE, LTE-advanced
- Picocells, femtocells and small cells
- Sampling clocks for ADC and DAC
- 1 Gigabit Ethernet
- 10 Gigabit Ethernet
- FPGA and processor clocks
