TC75202

new-10%

Manufacturer part number:TC75202

Manufacturer:Cornell Dubilier Electronics (CDE)

Description:CAP ALUM 2000UF 75V AXIAL

Case Package:SOT-23

Datasheet:TC75202 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	Axial, Can
Terminal Shape	WIRE
Number of Pins	2
Dielectric Material	Aluminium
Operating Temperature	-40°C~85°C
Packaging	Bulk
Published	2011
Series	TC
Size / Dimension	1.000Diax2.625L 25.40mmx66.68mm
Tolerance	-10% +75%
JESD-609 Code	e0
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	Axial
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Applications	General Purpose
Capacitance	2000μF
Voltage - Rated DC	75V
Capacitor Type	ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance)	50mOhm @ 120Hz
Lifetime @ Temp	1000 Hrs @ 85°C
Ripple Current	3.991A
Polarization	Polar
Life (Hours)	1000 hours
Ripple Current @ Low Frequency	3.991A @ 120Hz
Ripple Current @ High Frequency	4.63A @ 2.4kHz
Diameter	25.4mm
Height	66.675mm
Length	66.68mm
REACH SVHC	Unknown
RoHS Status	Non-RoHS Compliant
