TC70

new-10%

Manufacturer part number:TC70

Manufacturer:Cornell Dubilier Electronics (CDE)

Description:CAP ALUM 5UF 450V AXIAL

Case Package:SOT-23

Datasheet:TC70 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	Axial, Can
Number of Pins	2
Dielectric Material	Aluminium
Operating Temperature	-40°C~85°C
Packaging	Bulk
Series	TC
Size / Dimension	0.750Diax1.125L 19.05mmx28.58mm
Tolerance	-10% +50%
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Axial
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Applications	General Purpose
Voltage - Rated	450V
Capacitance	5μF
Voltage - Rated DC	450V
ESR (Equivalent Series Resistance)	35.86Ohm @ 120Hz
Lifetime @ Temp	1000 Hrs @ 85°C
Ripple Current	144mA
Polarization	Polar
Life (Hours)	1000 hours
Ripple Current @ Low Frequency	144mA @ 120Hz
Ripple Current @ High Frequency	180mA @ 2.4kHz
Diameter	19.05mm
Height	28.575mm
Length	28.575mm
REACH SVHC	Unknown
RoHS Status	Non-RoHS Compliant
