M83513/15-H01NP

  • M83513/15-H01NP
  • M83513/15-H01NP

M83513/15-H01NP

M83513/15-H01NP

Cinch Connectivity Solutions

Military, MIL-C-83513, M83513 Series D-Type, Micro-D Receptacle, Female Sockets 100 Position-Position RCP Signal Solder 0.050 Pitch x 0.050 Row to Row Through Hole, Right Angle Copper Alloy

SOT-23

M83513/15-H01NP Datasheet

non-compliant

In-Stock: 70 items
Specifications
Name Value
Type Parameter
Contact Plating Gold
Contact Material Copper Alloy
Mounting Type Through Hole, Right Angle
Insulation Material Glass filled, Polyester
Shell Material Aluminum Alloy
Dielectric Material Polyester, Glass Filled
Number of Terminals 100
Shell Material, Finish Aluminum Alloy, Nickel Plated, Electroless
Mounting Style Board Mount
ECCN (US) EAR99
Termination Method Solder
Terminal Pitch (mm) 0.64
Body Orientation Right Angle
Maximum Current Rating (A) 3
Maximum Contact Resistance (mOhm) 8
Minimum Operating Temperature (°C) -55
Maximum Operating Temperature (°C) 125
Mating Cycle (Cycles) 500
Less Contact No
Tradename Dura-Con™
Mounting Through Hole
Manufacturer Cinch Connectivity Solutions
Brand Cinch
Package Bag
Base Product Number M83513/15
Mfr Cinch Connectivity Solutions
Product Status Active
Operating Temperature -55°C ~ 125°C
Series Military, MIL-C-83513, M83513
Part Status Active
Termination Solder
Connector Type Receptacle, Female Sockets
Type Micro D-Subminiature
Number of Positions 100 Position
Color -
Number of Rows 4
Gender RCP
Subcategory MIL-Spec / MIL-Type
Contact Type Signal
Current Rating (Amps) 3A
Ingress Protection -
Current Rating 3 A
Contact Finish Gold
Termination Style Solder
Number of Contacts 100
Contact Gender SKT
Wire Gauge -
Flange Feature Mating Side, Female Screwlock (4-40)
Shell Size H
Connector Style D-Type, Micro-D
Number of Ports 1
Contact Form -
Shell Size, Connector Layout 0.050 Pitch x 0.050 Row to Row
Insulation Insulated
Product Type D-Sub MIL Spec Connectors
Backset Spacing 0.200 (5.08mm)
Shell Plating Electroless Nickel
Product Connectors
Mounting Angle Right Angle
Features -
Voltage Rating 600 VAC
Product Category D-Sub MIL Spec Connectors
Product Length (mm) 55.25
Contact Finish Thickness 50.0µin (1.27µm)
Product Height (mm) 9.75
RoHS Status Supplier Unconfirmed
Material Flammability Rating UL94 V-0
Pricing & Ordering
Quantity Unit Price Ext. Price
1 $303.01000 $303.01
500 $299.9799 $149989.95
1000 $296.9498 $296949.8
1500 $293.9197 $440879.55
2000 $290.8896 $581779.2
2500 $287.8595 $719648.75
M83513/15-H01NP Product Details

M83513/15-H01NP Overview


The product is packaged in Receptacle, Female Sockets.Through Hole, Right Angle is the mounting type.As a product of the Military, MIL-C-83513, M83513 Series, it can be found in this category.A variety of tasks can be managed via its 1 ports.The device is operating at -55°C ~ 125°C Operating Temperature.

M83513/15-H01NP Features


Military, MIL-C-83513, M83513 series


M83513/15-H01NP Applications


There are a lot of Cinch Connectivity Solutions
M83513/15-H01NP D-Sub Connectors applications.


  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
  • Electrical substations
  • Energy efficient lighting (LED)
  • LED municipal outdoor and street lighting
