Name: MP0045/1E0NN000
Brand: Bulgin
SKU: MP0045/1E0NN000
Price: 24.84000 USD
Availability: InStock

new

MP0045/1E0NN000

Manufacturer part number:MP0045/1E0NN000

Manufacturer:Bulgin

Description:MP0045/1E0NN000 datasheet pdf and Pushbutton Switches product details from Bulgin stock available on our website

Case Package:SOT-23

Datasheet:MP0045/1E0NN000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	24 Weeks
Mount	Front, Panel
Mounting Type	Panel Mount, Front
Material	Stainless Steel
Housing Material	Stainless Steel
Actuator Material	Stainless Steel
Operating Temperature	-20°C~55°C
Packaging	Bulk
Published	2007
JESD-609 Code	e3
Feature	Stainless Steel
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Type	Standard
Number of Positions	2
Terminal Finish	Tin (Sn)
Voltage - Rated	250V
HTS Code	8536.50.70.00
Current Rating (Amps)	3A AC
Orientation	Straight
Ingress Protection	IP40
Current Rating	3A
Termination Style	Solder Lug
Voltage - Rated AC	250V
Actuator Type	Round, Button, Flush
Circuit	DPDT
Switch Function	On-On
Panel Cutout Dimensions	Circular - 16.20mm Dia
Contact Resistance	50mOhm
Insulation Resistance	1GOhm
Color - Actuator/Cap	Silver
Max Voltage Rating (AC)	250V
Electrical Life	30,000 Cycles
Throw Configuration	DPDT, DPST
Mechanical Life	200,000 Cycles
Contact Current Rating	3A
Contact Current(AC)-Max	3A
Actuator Length	0m
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant

MP0045/1E0NN000 Product Details

Description: The Bulgin MP0045/1E0NN000 is a vandal resistant switch from the Low Profile Series. It is a double pole double throw (DPDT) switch with a natural finish and solder terminals. It is rated for 3A at 250VAC.

Features:
• Vandal resistant design
• Low profile design
• DPDT-CO switch
• Natural finish
• Solder terminals
• 3A rating at 250VAC

Applications: The Bulgin MP0045/1E0NN000 is suitable for a variety of applications, including security systems, access control systems, and other applications where a vandal resistant switch is required. It is also suitable for use in industrial and commercial environments.
