EP2AGX95DF25C6N Overview
There is a 572-BGA, FCBGA package that includes this component. In this kind of FPGA, FIELD PROGRAMMABLE GATE ARRAY is used. A total of 260 I/Os are programmed to ensure a more coherent data transfer. A fundamental building block is made up of 89178 logic elements/cells. Supply voltage is 0.9V volts. A Field Programmable Gate Arrays-series FPGA part. The Surface Mount-slot connector on the FPGA module can be connected to the development board. There is a 0.87V~0.93V-volt supply voltage required for the device to operate. The FPGA belongs to the Arria II GX series of FPGAs, and it is one type of FPGA. Fpga chips is recommended that the operating temperature be kept wFpga chipshin the range 0°C~85°C TJ while the machine is operating. A device such as this one has 260 outputs built into it. As a space-saving measure, this FPGA model is contained within Tray. Total terminations are 572. Fpga chips is important to note that this device has a RAM capacFpga chipsy of 6839296 bFpga chipss. Parts related to this part can be found using its base part number EP2AGX95. The FPGA is built as an array of 3747 latches or CLBs. Power is provided by a 0.91.2/3.31.52.5V battery that is included with the device. Fpga semiconductor typically uses a crystal oscillating at 500MHz.
EP2AGX95DF25C6N Features
260 I/Os
Up to 6839296 RAM bits
EP2AGX95DF25C6N Applications
There are a lot of Intel EP2AGX95DF25C6N FPGAs applications.
- Secure Communication
- Cryptography
- ADAS
- Automotive
- Security systems
- Broadcast
- OpenCL
- Radar and Sensors
- Telecommunication
- Wireless Communications
