EP2AGX65DF29C4 Overview
A 780-BBGA, FCBGA package is provided with this component. There are FIELD PROGRAMMABLE GATE ARRAY transistors in this type of FPGA. The I/Os are designed to facilitate a more coherent transfer of data. There are 60214 logic elements/cells to form a fundamental building block. The Field Programmable Gate Arrays family of FPGAs includes this part. With a Surface Mount connector, this FPGA module can be attached to the development board. A supply voltage of 0.87V~0.93V is needed in order for fpga chips to operate. An FPGA belonging to the Arria II GX series is referred to as an FPGA. Fpga chips is recommended that the operating temperature be kept wFpga chipshin the range 0°C~85°C TJ while the machine is operating. During the installation of this device, 364 outputs were incorporated. A model of this FPGA is contained in Tray for the purpose of saving space. In total, the terminations of this piece are 780. A device like this one offers 5371904 RAM bits, which is a considerable amount of memory. For related parts, use its base part number EP2AGX65. This FPGA is built as an array of 2530 LABs/CLBs. Power is supplied to the device by a 0.91.2/3.31.52.5V battery.
EP2AGX65DF29C4 Features
364 I/Os
Up to 5371904 RAM bits
EP2AGX65DF29C4 Applications
There are a lot of Intel EP2AGX65DF29C4 FPGAs applications.
- ASIC prototyping
- Device controllers
- Medical Electronics
- Telecommunication
- Military Temperature
- Software-defined radios
- OpenCL
- Cryptography
- Consumer Electronics
- Space Applications
