Name: AM2520SECK09
Brand: Kingbright
SKU: AM2520SECK09
Price: 0.53000 USD
Availability: InStock

new-10%

AM2520SECK09

Manufacturer part number:AM2520SECK09

Manufacturer:Kingbright

Description:AM2520SECK09 datasheet pdf and LED Indication - Discrete product details from Kingbright stock available on our website

Case Package:SOT-23

Datasheet:AM2520SECK09 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount, Bottom Entry
Package / Case	2-SMD, Z-Bend
Packaging	Tape & Reel (TR)
Published	2011
Size / Dimension	2.50mm Lx2.00mm W
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	2
ECCN Code	EAR99
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Color	Orange
Additional Feature	HIGH RELIABILITY
HTS Code	8541.40.20.00
Packing Method	TAPE AND REEL
Number of Functions	1
Terminal Pitch	5.05mm
Configuration	Standard
Power Dissipation	75mW
Voltage - Forward (Vf) (Typ)	2.1V
Viewing Angle	20°
Optoelectronic Device Type	SINGLE COLOR LED
Forward Current	20mA
Lens Style	Round with Domed Top
Lens Size	1.90mm Dia
Luminous Intensity	3.5 cd
Millicandela Rating	1800mcd
Lens Transparency	Clear
Wavelength - Peak	610nm
Lens Color	Colorless
Reverse Voltage	5V
Wavelength - Dominant	601nm
T-code	T-3/4
Max Junction Temperature (Tj)	115°C
Height	1.5mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

AM2520SECK09 Product Details

Description: The Kingbright AM2520SECK09 is a discrete LED indication light with a 2.5x2mm package size. It has an orange water clear lens and is based on surface mount technology.

Features:
- 2.5x2mm package size
- Orange water clear lens
- Surface mount technology
- 601nm wavelength

Applications: The Kingbright AM2520SECK09 is suitable for a variety of applications, including automotive, industrial, and consumer electronics. It can be used as an indicator light, a warning light, or a decorative light.
