90142-0034

  • 90142-0034 - 2 Rows Receptacle, Socket Bulk Black 34 Positions PPO
  • 90142-0034 - 2 Rows Receptacle, Socket Bulk Black 34 Positions PPO

90142-0034

90142-0034

Molex

2 Rows Receptacle, Socket Bulk Black 34 Positions PPO

SOT-23

90142-0034 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 8 Weeks
Mount Cable, Free Hanging
Housing Material PPO
PackagingBulk
Published 2009
Pbfree Code yes
Part StatusActive
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 34
Max Operating Temperature105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Receptacle
Voltage - Rated 350V
HTS Code8536.69.40.40
Fastening TypeRamp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 34
Orientation Straight
Depth 15.24mm
Current Rating3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.303 inch
Contact Gender Female
UL Flammability Code 94V-1
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Insulation Resistance1000000000Ohm
Body/Shell Style PLUG
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1000VAC V
Max Voltage Rating (DC) 350.35kV
Contact Pattern RECTANGULAR
Halogen Free Low Halogen
Glow Wire Compliant Non-compliant
Length 43.18mm
Width 7.72mm
REACH SVHC Unknown
Radiation HardeningNo
RoHS StatusRoHS Compliant
Lead Free Lead Free
In-Stock:6321 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$1.04000$1.04
500$1.0296$514.8
1000$1.0192$1019.2
1500$1.0088$1513.2
2000$0.9984$1996.8
2500$0.988$2470

90142-0034 Product Details

90142-0034 Overview


A Receptacle, Socket package is included with it.Packaging is performed using a Bulk case.Cable, Free Hanging mounts the part.

90142-0034 Features




90142-0034 Applications


There are a lot of Molex
90142-0034 Rectangular Connectors applications.


  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
