5AGXMA3D4F27I5N Overview
Fpga chips is supplied in the 672-BBGA, FCBGA package. In this kind of FPGA, FIELD PROGRAMMABLE GATE ARRAY is used. A total of 336 I/Os are programmed to ensure a more coherent data transfer. There are 156000 logic elements/cells to form a fundamental building block. It is powered from a supply voltage of 1.1V. Part of the Field Programmable Gate Arrays family, this FPGA part is a programmable gate array. The Surface Mount-slot connector on the FPGA module can be connected to the development board. The supply voltage of the device is 1.07V~1.13V , at which it runs. The Arria V GX series FPGA is a type of FPGA that belongs to the Arria V GX family of FPGAs. Fpga chips is important to maintain the operating temperature wFpga chipshin the range of -40°C~100°C TJ when operating the machine. The device has 336 outputs that are integrated into it. This FPGA model is contained in Tray for space saving. Fpga chips is designed wFpga chipsh 672 terminations. Having a RAM bit size of 11746304 means that this device will offer you a lot of memory. For related parts, use its base part number 5AGXMA3. 7362 LABs/CLBs are integrated into this FPGA. An external power supply of 1.11.2/3.32.5V is required to power the device. Most of the time, it uses a crystal oscillating at 622MHz to generate the signal. For the building block, it encompasses 149430 logic cells that make up the logic circuit.
5AGXMA3D4F27I5N Features
336 I/Os
Up to 11746304 RAM bits
5AGXMA3D4F27I5N Applications
There are a lot of Intel 5AGXMA3D4F27I5N FPGAs applications.
- Device controllers
- Defense Applications
- Filtering and communication encoding
- Medical Applications
- Software-defined radios
- Video & Image Processing
- Artificial intelligence (AI)
- Aircraft navigation
- Industrial Ethernet
- Medical imaging
