5AGXBA1D4F27I5 Overview
This package is included in the 672-BBGA, FCBGA package and is available for purchase. In this kind of FPGA, FIELD PROGRAMMABLE GATE ARRAY is used. Having 336 I/Os makes data transfers more coherent. A fundamental building block consists of 75000 logic elements/cells. Fpga chips is powered from a supply voltage of 1.1V. The Surface Mount-slot on the development board allows you to attach the FPGA module. A supply voltage of 1.07V~1.13V is needed in order for fpga chips to operate. The FPGA belongs to the Arria V GX series of FPGAs, and it is one type of FPGA. In order to ensure a safe and efficient operation, it is important to maintain a temperature within -40°C~100°C TJ at all times. A model of this FPGA is contained in Tray for the purpose of saving space. Total terminations are 672. There are 8666112 RAM bits that are available with this device. In order to find related parts, use the part number 5AGXBA1 as a base. 3537 LABs/CLBs are integrated into this FPGA. Fpga semiconductor typically uses a crystal oscillating at 622MHz.
5AGXBA1D4F27I5 Features
336 I/Os
Up to 8666112 RAM bits
5AGXBA1D4F27I5 Applications
There are a lot of Intel 5AGXBA1D4F27I5 FPGAs applications.
- ASIC prototyping
- Defense Applications
- High Performance Computing
- Aircraft navigation
- Automotive driver's assistance
- Data center hardware accelerators
- Device controllers
- Data Center
- Video & Image Processing
- Automotive
