10M08SCU324C8G Overview
Fpga chips is supplied in the 324-LFBGA package. In this kind of FPGA, FIELD PROGRAMMABLE GATE ARRAY is used. There are 246 I/Os for better data transfer. To form a fundamental building block, there are 8000 logic elements/cells. Using a Surface Mount connector, you can mount this FPGA module on the development board. With a supply voltage of 2.85V~3.465V, this device operates with ease. As part of the MAX? 10 series of FPGAs, it is a type of FPGA. Fpga chips is necessary to keep the operating temperature wFpga chipshin 0°C~85°C TJ when the device is operating. As a space-saving measure, this FPGA model is contained within Tray. The RAM bits that this device offer is 387072. 500 LABs/CLBs are integrated into this FPGA.
10M08SCU324C8G Features
246 I/Os
Up to 387072 RAM bits
10M08SCU324C8G Applications
There are a lot of Intel 10M08SCU324C8G FPGAs applications.
- Medical ultrasounds
- Filtering and communication encoding
- Audio
- Data Mining
- Enterprise networking
- Data center search engines
- Voice recognition
- Solar Energy
- Wireless Communications
- Video & Image Processing
