10M08SAE144C8G Description
Power-efficient dual-mode transceivers with 57.8 Gbps PAM4 (Pulse Amplitude Modulation) and 28.9 Gbps NRZ (Non Return to Zero) operation are available in Intel® Stratix® 10 TX FPGAs. These devices can provide over 8 Tbps of aggregate bandwidth, fulfilling the strict transceiver bandwidth and power budget constraints of next-generation designs thanks to hardened PCI Express Gen 3 and 10/25/100 Gbps Ethernet MAC IP blocks.
The 57.8 Gbps PAM4 / 28.9 Gbps NRZ dual-mode transceivers are only one ground-breaking innovation included in the Intel Stratix 10 TX devices' list of advanced features. These include Intel's Embedded Multi-die Interconnect Bridge-based advanced packaging technology, protected external memory controllers, hardened floating point DSP blocks, and an entirely new HyperFlex® core architecture (EMIB).
10M08SAE144C8G Features
All new Intel Hyperflex™ core architecture delivering 2X the core performance compared to previous generation high-performance FPGAs
Intel 14 nm tri-gate (FinFET) technology
Heterogeneous 3D System-in-Package (SiP) technology
Monolithic core fabric with up to 2.8 million logic elements (LEs)
Up to 144 full duplex transceiver channels on heterogeneous 3D SiP transceiver tiles
Transceiver data rates up to 57.8 Gbps PAM4 and 28.9 Gbps NRZ for chip-to-chip, chip-to-module, and backplane applications
Embedded eSRAM (47.25 Mbit) in select devices, and M20K (20 Kb) internal SRAM memory blocks
Fractional synthesis and ultra-low jitter LC tank based transmit phase locked loops (PLLs)
Hard PCI Express® Gen3 x16 intellectual property (IP) blocks
Hard 10/25/100 Gbps Ethernet MAC with dedicated Reed-Solomon FEC for NRZ signals (528, 514) and PAM4 signals (544, 514)
10M08SAE144C8G Applications
Temperature Measurement
Pressure Measurement
Flow Meters
Factory Automation and Process Control
