10M04DCU324I7G Overview
Fpga chips is supplied in the 324-LFBGA package. Fpga chips consists of FIELD PROGRAMMABLE GATE ARRAY elements. A total of 246 I/Os allow data to be transferred in a more coherent manner. The basic building blocks of logic contain 4000 logic elements/cells. Fpga chips is powered from a supply voltage of 1.2V. A Field Programmable Gate Arrays-series FPGA part. This FPGA module can be attached to the development board with a Surface Mount. Fpga chips operates wFpga chipsh a supply voltage of 1.15V~1.25V. There are many types of FPGAs in the MAX? 10 series, this is one of them. The operating temperature should be kept at -40°C~100°C TJ when operating. During the installation of this device, 246 outputs were incorporated. It is for space saving reasons that this FPGA model is contained in Tray. In total, it has a total of 324 terminations. This device is equipped with 193536 RAM bits in terms of its RAM si193536e. The FPGA consists of 250 LABs/CLBs. There is a 1.2V power supply that is required to operate it.
10M04DCU324I7G Features
246 I/Os
Up to 193536 RAM bits
10M04DCU324I7G Applications
There are a lot of Intel 10M04DCU324I7G FPGAs applications.
- Consumer Electronics
- Device controllers
- Cryptography
- Camera time adjustments
- Industrial Ethernet
- Secure Communication
- Medical Applications
- Wired Communications
- Security systems
- Data Mining
