10AX022E3F27I2SG Overview
Fpga chips is supplied in the 672-BBGA, FCBGA package. This kind of FPGA is composed of FIELD PROGRAMMABLE GATE ARRAY. This device features 240 I/Os in order to transfer data in a more efficient manner. A fundamental building block is made up of 220000 logic elements/cells. 0.9V volts power it. A Field Programmable Gate Arrays-series FPGA part. The Surface Mount-slot connector on the FPGA module can be connected to the development board. With a supply voltage of 0.87V~0.93V, this device operates with ease. The FPGA belongs to the Arria 10 GX series of FPGAs, and it is one type of FPGA. While operating, the operating temperature should be kept within a range of -40°C~100°C TJ. A total of 240 outputs are incorporated into this device. There is an FPGA model contained in Tray in order to conserve space. In total, the terminations of this piece are 672. The RAM bits that are offered by this fpga chips are 13752320. A total of 80330 LABs/CLBs are included in this FPGA. In order for fpga electronics to work, fpga electronics requires a 0.9V power supply.
10AX022E3F27I2SG Features
240 I/Os
Up to 13752320 RAM bits
10AX022E3F27I2SG Applications
There are a lot of Intel 10AX022E3F27I2SG FPGAs applications.
- Filtering and communication encoding
- Medical ultrasounds
- Enterprise networking
- Security systems
- Random logic
- Aircraft navigation
- ASIC prototyping
- Telecommunication
- Software-defined radios
- Wired Communications
