Name: 0901361209
Brand: Molex
SKU: 0901361209
Price: 2.27000 USD
Availability: InStock

new-10%

0901361209

Manufacturer part number:0901361209

Manufacturer:Molex

Description:C-Grid III 90136 Series 1-Row Header Solder Brass Tray Through Hole Gold Polyester, Glass Filled 9-Position Board to Cable/Wire 0.429 10.90mm Height

Case Package:SOT-23

Datasheet:0901361209 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Brass
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polyester, Glass Filled
Packaging	Tray
Series	C-Grid III 90136
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	9
Applications	Automotive, General Purpose
Number of Rows	1
Fastening Type	Latch Holder
Contact Finish - Mating	Gold
Contact Type	Male Pin
Insulation Height	0.429 10.90mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Contact Length - Post	0.114 2.90mm
Shrouding	Shrouded - 4 Wall
Contact Finish - Post	Tin
Contact Length - Mating	0.266 6.75mm
Overall Contact Length	0.510 12.95mm
Contact Finish Thickness - Mating	15.0μin 0.38μm
Contact Finish Thickness - Post	118.1μin 3.00μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0901361209 Product Details

0901361209 Overview

Packaging for this item is Header.There is a mounting type of Through Hole for this device.It is necessary to use a Tray case for packaging the product.This product is part of the C-Grid III 90136 Series.A possible application for the device is Automotive, General Purpose.
