Name: 0702800793
Brand: Molex
SKU: 0702800793
Price: 0.90000 USD
Availability: InStock

new-10%

0702800793

Manufacturer part number:0702800793

Manufacturer:Molex

Description:C-Grid 70280 Series 2-Row Header, Breakaway Solder Copper Alloy Bulk Through Hole Gold Liquid Crystal Polymer (LCP), Glass Filled 10-Position Board to Board or Cable 0.090 2.29mm Height

Case Package:SOT-23

Datasheet:0702800793 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Contact Material	Copper Alloy
Contact Plating	Gold
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP), Glass Filled
Housing Material	Polymer
Packaging	Bulk
Series	C-Grid 70280
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Breakaway
Number of Positions	10
Max Operating Temperature	105°C
Min Operating Temperature	-40°C
Color	Black
Applications	Automotive, General Purpose, Lighting, Medical, Telecommunications
Number of Rows	2
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Type	Male Pin
Pitch	2.54mm
Orientation	Straight
Depth	5.08mm
Insulation Height	0.090 2.29mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.185 4.70mm
Shrouding	Unshrouded
Number of Contacts	10
Contact Finish - Post	Tin
Contact Length - Mating	0.320 8.13mm
Housing Color	Black
Overall Contact Length	0.595 15.11mm
Contact Resistance	15mOhm
Max Voltage Rating (AC)	250V
Length	12.7mm
Contact Finish Thickness - Mating	30.0μin 0.76μm
Contact Finish Thickness - Post	74.8μin 1.90μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0702800793 Product Details

0702800793 Overview

Packaging is in the form of Header, Breakaway.This device has a Through Hole mounting type.An orange Bulk case is used to package the product.Specifically, it is one of the products in the C-Grid 70280 Series.If the temperature is below 105°C, it's best to use it.-40°C is the minimum temperature for this device.There are a variety of possible applications for this device, including Automotive, General Purpose, Lighting, Medical, Telecommunications.There is a mounting hole at Through Hole.
