Name: 0395337009
Brand: Molex
SKU: 0395337009
Price: 7.49000 USD
Availability: InStock

new-10%

0395337009

Manufacturer part number:0395337009

Manufacturer:Molex

Description:0395337009 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0395337009 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Phosphor Bronze
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~105°C
Packaging	Bulk
Series	Eurostyle ESE 39533
Feature	Retention Latches (Non-Wire Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Type	Plug, Female Sockets
Color	Green
Pitch	0.200 5.08mm
Orientation	Straight
Insulation Height	1.020 25.91mm
Reach Compliance Code	unknown
Termination Style	Screw - Rising Cage Clamp
Voltage	300V
Max Supply Voltage	300V
Number of Levels	1
Current	15A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Wire Gauge or Range - AWG	12-26 AWG
Torque - Screw	0.56 Nm (5.0 Lb-In)
Plug Wire Entry	270°
Wire Strip Length	5mm
Number of Positions Per Level	9
Length	45.72mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0395337009 Product Details

0395337009 Overview

This device's mounting type is Free Hanging (In-Line).An orange Bulk case is used to package the product.Among the products in the Eurostyle ESE 39533 Series, it is one of the most popular.As a result of its Retention Latches (Non-Wire Side) feature, it possesses a great deal of power.In this case, Cable, Free Hanging mounts the part.Device runs in -40°C~105°C operating temperature.This chip should not be supplied with a voltage greater than 300V.This part shares lots of benefits with other Plug, Female Sockets products.
