Name: 0395225003
Brand: Molex
SKU: 0395225003
Price: 1.22000 USD
Availability: InStock

new-10%

0395225003

Manufacturer part number:0395225003

Manufacturer:Molex

Description:0395225003 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0395225003 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Brass
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~105°C
Packaging	Bulk
Series	Eurostyle ESE 39522
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Type	Header, Male Pins, Shrouded (2 Side)
Number of Positions	3
Color	Green
Pitch	0.197 5.00mm
Orientation	Right Angle
Depth	12mm
Insulation Height	0.330 8.38mm
Reach Compliance Code	unknown
Termination Style	Solder
Voltage	300V
Contact Tail Length	0.150 3.81mm
Max Voltage Rating (AC)	300V
Number of Levels	1
Current	15A
Contact Mating Finish	Tin
Header Orientation	90°, Right Angle
Length	17mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0395225003 Product Details

0395225003 Overview

This device has a Through Hole mounting type.Packaged in a Bulk case.Specifically, it is one of the products in the Eurostyle ESE 39522 Series.Mounting of the part is based on Through Hole.It operates at an operating temperature of -40°C~105°C.Other Header, Male Pins, Shrouded (2 Side) products share lots of benefits with this part.
