Molex

0395078010 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

SOT-23

0395078010 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Contact MaterialPhosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Operating Temperature-40°C~115°C
PackagingBulk
Series Eurostyle ESE 39507
Feature Mating Flange
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 10
Color Green
Pitch 0.138 3.50mm
Insulation Height 0.740 18.80mm
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-30 AWG
Current - UL 8A
Torque - Screw 0.23 Nm (2.0 Lb-In)
Plug Wire Entry 90°
Wire Strip Length 6.5mm
Screw Size M2
Material Flammability Rating UL94 V-0
RoHS StatusROHS3 Compliant
In-Stock:2099 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$3.984445$3.984445
10$3.758910$37.5891
100$3.546142$354.6142
500$3.345416$1672.708
1000$3.156053$3156.053

0395078010 Product Details

0395078010 Overview


Free Hanging (In-Line) indicates that the device is mounted.A Bulk case is used to package the product.It's from the Eurostyle ESE 39507 Series.This feature makes it more powerful in a number of ways due to its Mating Flange feature.This device operates at a temperature of -40°C~115°C.There are a lot of similarities between this part and other Plug, Female Sockets products.

0395078010 Features


Eurostyle ESE 39507 series

0395078010 Applications


There are a lot of Molex 0395078010 Terminal Blocks applications.

  • Military Technology
  • Instrumentation
  • Measuring & Control Technology
  • LED municipal outdoor and street lighting
  • Anywhere power is distributed
  • Medical technology
  • Electrical substations
  • Refrigeration control
  • Control panels
  • Industrial Automation
