0395078003

0395078003

0395078003

Molex

0395078003 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

SOT-23

0395078003 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Contact MaterialPhosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Operating Temperature-40°C~115°C
PackagingBulk
Series Eurostyle ESE 39507
Feature Mating Flange
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 3
Color Green
Pitch 0.138 3.50mm
Insulation Height 0.740 18.80mm
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-30 AWG
Current - UL 8A
Torque - Screw 0.23 Nm (2.0 Lb-In)
Plug Wire Entry 90°
Wire Strip Length 6.5mm
Screw Size M2
Material Flammability Rating UL94 V-0
RoHS StatusROHS3 Compliant
In-Stock:4278 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$1.514163$1.514163
10$1.428455$14.28455
100$1.347600$134.76
500$1.271321$635.6605
1000$1.199359$1199.359

0395078003 Product Details

0395078003 Overview


There is a Free Hanging (In-Line) mounting type for the device.We package the product with a Bulk case.This product is in the Eurostyle ESE 39507 Series.This feature makes it more powerful in a number of ways due to its Mating Flange feature.-40°C~115°C Operating Temperature is used by the device.Many Plug, Female Sockets products share the same benefits as this part.

0395078003 Features


Eurostyle ESE 39507 series

0395078003 Applications


There are a lot of Molex 0395078003 Terminal Blocks applications.

  • Communication
  • Industrial Automation
  • Control panels
  • Military Technology
  • Instrumentation
  • Medical technology
  • Blowers
  • Measuring & Control Technology
  • Automotive Electronics
  • Datacom
