0395005011

0395005011

0395005011

Molex

0395005011 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

SOT-23

0395005011 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Contact MaterialPhosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Operating Temperature-40°C~115°C
PackagingBulk
Series Eurostyle ESE 39500
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 11
Color Green
Pitch 0.138 3.50mm
Insulation Height 0.440 11.18mm
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-30 AWG
Current - UL 8A
Torque - Screw 0.23 Nm (2.0 Lb-In)
Plug Wire Entry 180°
Wire Strip Length 6.5mm
Material Flammability Rating UL94 V-0
RoHS StatusROHS3 Compliant
In-Stock:3486 items

Pricing & Ordering

QuantityUnit PriceExt. Price
756$2.02639$1531.95084

0395005011 Product Details

0395005011 Overview


There is a mounting type of Free Hanging (In-Line) for this device.We pack the product in a Bulk case.This product is in the Eurostyle ESE 39500 Series.In this case, the device operates at -40°C~115°C Operating Temperature.As with other Plug, Female Sockets products, this part has a lot of benefits.

0395005011 Features


Eurostyle ESE 39500 series

0395005011 Applications


There are a lot of Molex 0395005011 Terminal Blocks applications.

  • Blowers
  • Military Technology
  • Medical technology
  • LED municipal outdoor and street lighting
  • Automotive Electronics
  • Anywhere power is distributed
  • Energy efficient lighting (LED)
  • Datacom
  • Industrial Automation
  • Electrical substations
