Name: 0026603080
Brand: Molex
SKU: 0026603080
Price: 1.73000 USD
Availability: InStock

new-10%

0026603080

Manufacturer part number:0026603080

Manufacturer:Molex

Description:0026603080 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0026603080 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Contact Material	BRASS
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polyester, Glass Filled
Packaging	Bulk
Series	KK 41772
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	8
Applications	Automotive, General Purpose, Industrial, Medical, Telecommunications
Number of Rows	1
Additional Feature	POLARIZED
Fastening Type	Push-Pull
Contact Finish - Mating	Tin
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Terminal Pitch	3.96mm
Insulation Height	0.130 3.30mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.156 3.96mm
Insulation Color	Natural
Contact Length - Post	0.140 3.56mm
Shrouding	Unshrouded
Contact Length - Mating	0.585 14.86mm
UL Flammability Code	94V-0
Contact Finish Thickness - Mating	60.0μin 1.52μm
Contact Finish Thickness - Post	60.0μin 1.52μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0026603080 Product Details

0026603080 Overview

It comes in a Header package.Its mounting type is Through Hole, Right Angle.Bulk cases are used to package the product.The product belongs to the KK 41772 Series.Furthermore, there are other features such as POLARIZED, to name a few.This device can be used for Automotive, General Purpose, Industrial, Medical, Telecommunications.
