Name: 0022286053
Brand: Molex
SKU: 0022286053
Price: 0.29000 USD
Availability: InStock

new-10%

0022286053

Manufacturer part number:0022286053

Manufacturer:Molex

Description:0022286053 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0022286053 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Contact Material	Bronze
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon, Glass Filled
Material	Brass
Housing Material	Nylon
Packaging	Bulk
Series	KK 42376
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Breakaway
Max Operating Temperature	75°C
Min Operating Temperature	0°C
Applications	Automotive, General Purpose, Medical, Telecommunications
Number of Rows	1
Gender	Male
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Orientation	Right Angle
Depth	11.53mm
Insulation Height	0.090 2.29mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Current Rating	4A
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Contact Length - Post	0.120 3.05mm
Shrouding	Unshrouded
Number of Contacts	5
Contact Finish - Post	Tin
Contact Length - Mating	0.405 10.29mm
UL Flammability Code	94V-0
Contact Resistance	20mOhm
Max Voltage Rating (AC)	250V
Length	12.7mm
Contact Finish Thickness - Mating	15.0μin 0.38μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0022286053 Product Details

0022286053 Overview

You'll get Header, Breakaway packages.Through Hole, Right Angle is the type of mounting for the device.In order to package the product, a Bulk case is used.It's from the KK 42376 Series.Whenever it's below 75°C, it's best to use it.There's a minimum temperature of 0°C for this device.There is the possibility of using the device for Automotive, General Purpose, Medical, Telecommunications.In this case, Through Hole mounts the part.
