Name: 0022284243
Brand: Molex
SKU: 0022284243
Price: 1.57000 USD
Availability: InStock

new-10%

0022284243

Manufacturer part number:0022284243

Manufacturer:Molex

Description:0022284243 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0022284243 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Bronze
Contact Plating	Gold
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon, Glass Filled
Housing Material	Nylon
Packaging	Bulk
Series	KK 42375
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Breakaway
Number of Positions	24
Max Operating Temperature	75°C
Min Operating Temperature	0°C
Color	Black
Applications	Automotive, General Purpose, Medical, Telecommunications
Number of Rows	1
Gender	Male
Fastening Type	Push-Pull
Voltage - Rated DC	250V
Contact Finish - Mating	Gold
Contact Type	Male Pin
Pitch	2.54mm
Orientation	Vertical
Depth	2.49mm
Insulation Height	0.090 2.29mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Current Rating	4A
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Contact Length - Post	0.125 3.18mm
Shrouding	Unshrouded
Lead Pitch	2.54mm
Number of Contacts	24
Contact Finish - Post	Tin
Contact Length - Mating	0.240 6.10mm
Housing Color	Black
Overall Contact Length	0.455 11.56mm
Contact Resistance	20mOhm
Number of Circuits	24
Max Voltage Rating (AC)	250V
Length	60.96mm
Contact Finish Thickness - Mating	15.0μin 0.38μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

0022284243 Product Details

0022284243 Overview

You get it in Header, Breakaway packaging.There is a mounting type of Through Hole for this device.An Bulk case is utilized for packaging the product.It is part of the KK 42375 Series of products.It is best used at temperatures below 75°C.There is a minimum temperature requirement of [0°C] for this device.In addition to Automotive, General Purpose, Medical, Telecommunications, there are other possible applications for the device.By Through Hole, the part is mounted.This part contains circuits of type 24.
