Name: 0022284090
Brand: Molex
SKU: 0022284090
Price: 0.39000 USD
Availability: InStock

new-10%

0022284090

Manufacturer part number:0022284090

Manufacturer:Molex

Description:0022284090 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0022284090 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Brass
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon, Glass Filled
Housing Material	Thermoplastic
Packaging	Bulk
Series	KK 42375
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Breakaway
Applications	Automotive, General Purpose, Medical, Telecommunications
Number of Rows	1
Gender	Male
Voltage - Rated	250V
Fastening Type	Push-Pull
Voltage - Rated DC	250V
Contact Finish - Mating	Tin
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Orientation	Vertical
Insulation Height	0.090 2.29mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Current Rating	4A
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Contact Length - Post	0.125 3.18mm
Shrouding	Unshrouded
Lead Pitch	2.54mm
Number of Contacts	9
Contact Length - Mating	0.240 6.10mm
Overall Contact Length	0.455 11.56mm
Glow Wire Compliant	Non-compliant
Contact Finish Thickness - Mating	100.0μin 2.54μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-0
REACH SVHC	Unknown
RoHS Status	ROHS3 Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

0022284090 Product Details

0022284090 Overview

The product is packaged in Header, Breakaway.Through Hole is the type of mounting for the device.To package the product, a Bulk case is used.This is from the KK 42375 Series.A possible application for the device is Automotive, General Purpose, Medical, Telecommunications.Through Hole is mounting the part.
