Name: 0010977426
Brand: Molex
SKU: 0010977426
Price: 1.99000 USD
Availability: InStock

new-10%

0010977426

Manufacturer part number:0010977426

Manufacturer:Molex

Description:0010977426 datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0010977426 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Contact Material	Copper Alloy
Contact Plating	Gold
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP), Glass Filled
Housing Material	Polymer
Packaging	Bulk
Series	C-Grid 70280
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Breakaway
Number of Positions	42
Max Operating Temperature	120°C
Min Operating Temperature	-40°C
Color	Black
Applications	Automotive, General Purpose, Lighting, Medical, Telecommunications
Number of Rows	2
Gender	Male
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Type	Male Pin
Pitch	2.54mm
Orientation	Vertical
Depth	5.08mm
Insulation Height	0.090 2.29mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Current Rating	3A
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.110 2.79mm
Shrouding	Unshrouded
Number of Contacts	42
Contact Finish - Post	Tin
Contact Length - Mating	0.320 8.13mm
Housing Color	Black
Overall Contact Length	0.520 13.21mm
Contact Resistance	15mOhm
Number of Circuits	42
Length	53.34mm
Contact Finish Thickness - Mating	15.0μin 0.38μm
Contact Finish Thickness - Post	74.8μin 1.90μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0010977426 Product Details

0010977426 Overview

You get it in Header, Breakaway packaging.There is a mounting type of Through Hole for this device.It has been determined that a Bulk case is necessary to package the product.A member of the C-Grid 70280 Series.The ideal temperature for using it is below 120°C.-40°C is the minimum temperature for this device.This device can be used for Automotive, General Purpose, Lighting, Medical, Telecommunications.Through Hole represents the mounting point for the part.Circuits number 42 in the part.
