7007

new-10%

Manufacturer part number:7007

Manufacturer:Bourns Inc.

Description:7007 datasheet pdf and Arrays, Signal Transformers product details from Bourns Inc. stock available on our website

Case Package:SOT-23

Datasheet:7007 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	Radial, Vertical, 4 Leads
Number of Pins	4
Operating Temperature	-55°C~105°C
Packaging	Bulk
Series	7000
Size / Dimension	1.125Lx0.600W 28.58mmx15.24mm
Tolerance	±15%
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Radial
Resistance	20mOhm
Shielding	Unshielded
Current Rating	5A
Base Part Number	7000
Inductance	18.75 μH
DC Resistance (DCR)	20mOhm
Current	5A
Max DC Current	5A
Inductance Tolerance	15%
RMS Current (Irms)	5A
Inductance - Parallel	10 μH
Inductance - Series	40 μH
Number of Coils	2
DC Resistance (DCR) - Series	20mOhm Max
Current Rating - Series	5A
Inductance - Connected In Series	18.75μH
Height	1.250 31.75mm
Length	28.575mm
Width	15.24mm
REACH SVHC	No SVHC
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead
