Name: SLW26S-1C7
Brand: Amphenol ICC (FCI)
SKU: SLW26S-1C7
Availability: InStock

new-10%

SLW26S-1C7

Manufacturer part number:SLW26S-1C7

Manufacturer:Amphenol ICC (FCI)

Description:SLW26S-1C7 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Amphenol ICC (FCI) stock available on our website

Case Package:SOT-23

Datasheet:SLW26S-1C7 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon, Glass Filled
Actuator Material	Polyamide (PA), Nylon, Glass Filled
Operating Temperature	-55°C~105°C
Packaging	Tray
Series	SLW-S
JESD-609 Code	e3
Feature	Zero Insertion Force (ZIF)
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Kinked Pin
ECCN Code	EAR99
Connector Type	FFC/FPC CONNECTOR
Number of Positions	26
Number of Rows	1
Additional Feature	STAGGERED CONFIGURATION
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.039 1.00mm
Total Number of Contacts	26
Orientation	Straight
Depth	4mm
Current Rating	1A
Reference Standard	UL
Contact Finish	Tin Alloy
Voltage - Rated AC	100V
Reliability	COMMERCIAL
Number Of PCB Rows	2
PCB Contact Pattern	STAGGERED
Contact Gender	FEMALE
UL Flammability Code	94V-0
Housing Color	Black
Rated Current (Signal)	1A
Contact Style	SINGLE PRONG
Contact Resistance	30mOhm
Insulation Resistance	500MOhm
Max Voltage Rating (AC)	100V
PCB Contact Row Spacing	2.0066 mm
Contact Pattern	RECTANGULAR
Insertion Force-Max	ZIF N
Withdrawl Force-Min	ZIF N
Mating Cycles	20
Flat Flex Type	FFC, FPC
Connector/Contact Type	Contacts, Vertical - 1 Sided
Cable End Type	Straight, Tapered
Locking Feature	Slide Lock
Contact Location	Bottom
Length	32.2mm
Height Above Board	0.217 5.50mm
FFC, FCB Thickness	0.30mm 0.33mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Flammability Rating	UL94 V-0

SLW26S-1C7 Product Details

SLW26S-1C7 Overview

A FFC/FPC CONNECTOR packaging is included.This device's mounting type is Through Hole.Packaging for the product is carried out via a Tray case.It's part of the SLW-S Series.Further, there are features such as STAGGERED CONFIGURATION, to name only a few.A number of advantages can be derived from its Zero Insertion Force (ZIF) feature.Through Hole is mounting the part.The device is operating at -55°C~105°C Operating Temperature.
