Name: HFW5R-2STE1LF
Brand: Amphenol ICC (FCI)
SKU: HFW5R-2STE1LF
Price: 0.19000 USD
Availability: InStock

new-10%

HFW5R-2STE1LF

Manufacturer part number:HFW5R-2STE1LF

Manufacturer:Amphenol ICC (FCI)

Description:HFW5R-2STE1LF datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Amphenol ICC (FCI) stock available on our website

Case Package:SOT-23

Datasheet:HFW5R-2STE1LF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Polyamide (PA6T), Nylon 6T, Glass Filled
Operating Temperature	-55°C~105°C
Packaging	Tape & Reel (TR)
Published	2008
Series	HFW-R
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	5
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Number of Rows	1
Voltage - Rated	100V
Current Rating (Amps)	1A
Pitch	0.039 1.00mm
Orientation	Right Angle
Depth	5.5mm
Current Rating	1A
Contact Finish	Tin
Voltage - Rated AC	100V
Number of Contacts	5
Housing Color	Black
Contact Resistance	30mOhm
Insulation Resistance	500MOhm
Max Voltage Rating (AC)	100V
Wire/Cable Type	Straight
Mating Cycles	30
Flat Flex Type	FFC, FPC
Connector/Contact Type	Contacts, Top
Cable End Type	Straight or Tapered
Contact Location	Top
Length	7.6mm
Width	5.5mm
Height Above Board	0.075 1.90mm
FFC, FCB Thickness	0.30mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

HFW5R-2STE1LF Product Details

HFW5R-2STE1LF Overview

The device's mounting type is Surface Mount, Right Angle.This product is packaged in a case marked Tape & Reel (TR).The product belongs to the HFW-R Series.It works best at below 105°C.Temperatures below -55°C are required for this device.Surface Mount is the mounting point for the part.In this case, the device runs at -55°C~105°C Operating Temperature.
