Name: MS27508E18B11P
Brand: Amphenol Aerospace Operations
SKU: MS27508E18B11P
Price: 51.23000 USD
Availability: InStock

new

MS27508E18B11P

Manufacturer part number:MS27508E18B11P

Manufacturer:Amphenol Aerospace Operations

Description:Receptacle, Male Pins Aluminum Panel Mount 11 Positions Crimp Gold Olive Drab Cadmium over Nickel Bulk N (Normal) Bayonet Lock

Case Package:SOT-23

Datasheet:MS27508E18B11P Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Material	Copper Alloy
Mount	Box, Flanges, Panel
Mounting Type	Panel Mount
Mounting Feature	Flange
Shell Material	Aluminum
Body Material	Aluminium
Operating Temperature	-65°C~200°C
Packaging	Bulk
Series	Military, MIL-DTL-38999 Series II, JT
Published	2006
JESD-609 Code	e4
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Crimp
Connector Type	Receptacle, Male Pins
Number of Positions	11
Color	Olive Drab
Applications	Aviation, Military
Gender	Receptacle
Voltage - Rated	1.25kV
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	YES
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Total Number of Contacts	11
Orientation	N (Normal)
Shielding	Unshielded
Ingress Protection	Environment Resistant
Depth	33.32mm
Current Rating	13A
Military Standard	MIL-DTL-38999
Shell Finish	Olive Drab Cadmium over Nickel
Shell Size - Insert	18-11
Contact Gender	Male
Empty Shell	NO
Backshell Type	SOLID
Contact Style	Pin
Plating	Cadmium
Wire/Cable Gauge	16 AWG
Length	17.06mm
Contact Finish Thickness - Mating	50.0μin 1.27μm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Ratings	Environment Resistant

MS27508E18B11P Product Details

MS27508E18B11P Overview

Packaging is in the form of Receptacle, Male Pins.This device has a Panel Mount mounting type.An orange Bulk case is used to package the product.Specifically, it is one of the products in the Military, MIL-DTL-38999 Series II, JT Series.There is a mounting hole at Box, Flanges, Panel.Devices operate at -65°C~200°C operating temperatures.
