Name: MS27508E14F18SA
Brand: Amphenol Aerospace Operations
SKU: MS27508E14F18SA
Price: 54.83000 USD
Availability: InStock

new

MS27508E14F18SA

Manufacturer part number:MS27508E14F18SA

Manufacturer:Amphenol Aerospace Operations

Description:Receptacle, Female SocketsAluminumPanel Mount18 PositionsCrimpGoldElectroless NickelBulkABayonet Lock

Case Package:SOT-23

Datasheet:MS27508E14F18SA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Material	Copper Alloy
Mount	Box, Flanges, Panel
Mounting Type	Panel Mount
Mounting Feature	Flange
Shell Material	Aluminum
Operating Temperature	-65°C~200°C
Packaging	Bulk
Published	2006
Series	Military, MIL-DTL-38999 Series II, JT
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Crimp
Connector Type	Receptacle, Female Sockets
Number of Positions	18
Color	Silver
Applications	Aviation, Military
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	YES
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Total Number of Contacts	18
Orientation	A
Shielding	Unshielded
Ingress Protection	Environment Resistant
Depth	28.57mm
Current Rating	7.5A
Military Standard	MIL-DTL-38999
Shell Finish	Electroless Nickel
Shell Size - Insert	14-18
Contact Gender	Female
Empty Shell	NO
Backshell Type	SOLID
Contact Style	Socket
Plating	Electroless Nickel, Passivated, Steel
Length	17.06mm
Contact Finish Thickness - Mating	50.0μin 1.27μm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Ratings	Environment Resistant

MS27508E14F18SA Product Details

MS27508E14F18SA Overview

A Receptacle, Female Sockets package is included with it.Panel Mount indicates that the device is mounted.We pack the product in a Bulk case.It is part of the Military, MIL-DTL-38999 Series II, JT Series of products.Box, Flanges, Panel is mounting the part.As a result, the device runs at -65°C~200°C Operating Temperature.
