Name: MS27508E12B35PA
Brand: Amphenol Aerospace Operations
SKU: MS27508E12B35PA
Price: 62.55000 USD
Availability: InStock

new

MS27508E12B35PA

Manufacturer part number:MS27508E12B35PA

Manufacturer:Amphenol Aerospace Operations

Description:Receptacle, Male Pins Aluminum Panel Mount 22 Positions Crimp Gold Olive Drab Cadmium over Nickel Bulk A Bayonet Lock

Case Package:SOT-23

Datasheet:MS27508E12B35PA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Material	Copper Alloy
Mount	Box, Flanges, Panel
Mounting Type	Panel Mount
Mounting Feature	Flange
Shell Material	Aluminum
Body Material	Aluminium
Operating Temperature	-65°C~200°C
Packaging	Bulk
Series	Military, MIL-DTL-38999 Series II, JT
Published	2006
JESD-609 Code	e4
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Crimp
Connector Type	Receptacle, Male Pins
Number of Positions	22
Color	Olive Drab
Applications	Aviation, Military
Gender	Receptacle
Voltage - Rated	500V
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	YES
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Total Number of Contacts	22
Orientation	A
Shielding	Unshielded
Ingress Protection	Environment Resistant
Depth	26.18mm
Current Rating	5A
Military Standard	MIL-DTL-38999
Shell Finish	Olive Drab Cadmium over Nickel
Shell Size - Insert	12-35
Contact Gender	Male
Empty Shell	NO
Backshell Type	SOLID
Contact Style	Pin
Plating	Cadmium
Wire/Cable Gauge	22 AWG
Length	17.06mm
Contact Finish Thickness - Mating	50.0μin 1.27μm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Ratings	Environment Resistant

MS27508E12B35PA Product Details

MS27508E12B35PA Overview

The packaging contains Receptacle, Male Pins.There is a Panel Mount mounting type for the device.This product is packaged in a case marked Bulk.Product number Military, MIL-DTL-38999 Series II, JT belongs to the Military, MIL-DTL-38999 Series II, JT Series.There is a Box, Flanges, Panel mount on the part.This device operates at a temperature of -65°C~200°C.
