Name: UDK2559EB
Brand: Allegro MicroSystems
SKU: UDK2559EB
Availability: InStock

new-10%

UDK2559EB

Manufacturer part number:UDK2559EB

Manufacturer:Allegro MicroSystems

Description:5V Bipolar 1.27mm PMIC UDK2559 28 Pin 5V 28-LCC (J-Lead)

Case Package:SOT-23

Datasheet:UDK2559EB Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	28-LCC (J-Lead)
Number of Pins	28
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Published	2007
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	28
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Subcategory	Peripheral Drivers
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	240
Number of Functions	4
Supply Voltage	5V
Terminal Pitch	1.27mm
Reach Compliance Code	not_compliant
[email protected] Reflow Temperature-Max (s)	30
Base Part Number	UDK2559
Pin Count	28
Number of Outputs	4
Qualification Status	Not Qualified
Output Type	Bipolar
Max Output Current	1A
Supply Voltage-Max (Vsup)	5.25V
Power Supplies	5V
Interface	On/Off
Nominal Supply Current	80mA
Output Configuration	Low Side
Voltage - Supply (Vcc/Vdd)	4.75V~5.25V
Input Type	Non-Inverting
Switch Type	General Purpose
Output Characteristics	OPEN-COLLECTOR
Output Current per Channel	700mA
Output Polarity	INVERTED
Ratio - Input:Output	1:1
Input Characteristics	STANDARD
Voltage - Load	60V Max
Driver Number of Bits	4
Fault Protection	Current Limiting (Fixed), Over Temperature
Turn On Time	20 μs
Output Peak Current Limit-Nom	1A
Built-in Protections	TRANSIENT; OVER CURRENT; THERMAL
Output Current Flow Direction	SINK
Length	11.51mm
Width	11.51mm
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

UDK2559EB Product Details

UDK2559EB Overview

It is package in Tube case.Package 28-LCC (J-Lead) contains it.This LED driving board is mounted using the mounting type Surface Mount.This switch is of type General Purpose.Keeping the temperature at -40°C~125°C TA ensures reliable operation.There are 4 outputs available on this lighting driver.A voltage of 4.75V~5.25V is used to power it.A maximum output voltage of Bipolar volts can be obtained with this LED driver.It is a member of the UDK2559 family.It contains 28 terminations.For operation, we use the 28 pins.It contains 4 functions.This operation requires the maximum output current to be decreased to 1A.It is possible to achieve a high level of efficiency with a supply voltage of 5V.The lighting driver is mounted in the direction of Surface Mount.The LED driver has a total of 28 pins.A self-contained LED driver with a capacity of Peripheral Drivers is contained in an econtainer.The lighting driver is configured to have a maximum supply voltage of 5.25V (Vsup).In this part, the power supply is set to 5V.
