MS3450LS22-12PW-LC

  • MS3450LS22-12PW-LC - Circular
  • MS3450LS22-12PW-LC - Circular

MS3450LS22-12PW-LC

MS3450LS22-12PW-LC

Aero-Electric Connector

Circular

SOT-23

MS3450LS22-12PW-LC Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Contact MaterialBeryllium Copper
Number of Terminals 5
Mounting Style Wall
ECCN (US) EAR99
AEC Qualified No
Mounting Wall Mount
Body Orientation Straight
Termination Method Crimp
Shell Size / Insert Arrangement 22-12
Less Contact Yes
Maximum Voltage Rating 900VAC|1250VDC
Minimum Operating Temperature (°C) -55
Maximum Operating Temperature (°C) 200
Mating Style Threaded
Mating Cycle (Cycles) 100
Product Depth (mm) 41.28
Operating Temp Range -55C to 200C
Product Diameter (mm) Not Required(mm)
Rad Hardened No
Contact Classification 2POWER/3SIGNAL
RoHS Non-Compliant
Part StatusActive
Connector Type Circular
Type Circular
Gender RCP
Military Standard MIL-DTL-5015
Number of Contacts 5
Contact Gender PIN
Polarization W
Number of Ports1
Family MS34
Wire Size (AWG) (8-10)/(16-20)
Shell PlatingPassivated
Voltage Rating1250VDC/900VAC
Strain Relief No
Product Length (mm) 63.5
Product Height (mm) 41.28
RoHS StatusRoHS Compliant
In-Stock:93 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$134.98000$134.98
500$133.6302$66815.1
1000$132.2804$132280.4
1500$130.9306$196395.9
2000$129.5808$259161.6
2500$128.231$320577.5

MS3450LS22-12PW-LC Product Details

MS3450LS22-12PW-LC Overview


Packaging is in the form of Circular.

MS3450LS22-12PW-LC Features




MS3450LS22-12PW-LC Applications


There are a lot of Aero-Electric Connector
MS3450LS22-12PW-LC Circular Connectors applications.


  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
  • Electrical substations
  • Energy efficient lighting (LED)
  • LED municipal outdoor and street lighting
  • All Electrical Machinery
