CEN-100-20

new-10%

Manufacturer part number:CEN-100-20

Manufacturer:MEAN WELL USA Inc.

Description:LED DRIVER CC AC/DC 13-20V 4.8A

Case Package:SOT-23

Datasheet:CEN-100-20 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Mount	Screw
Mounting Type	Chassis Mount
Number of Pins	5
Operating Temperature	-30°C~70°C
Series	CEN-100 (100W)
Size / Dimension	6.85Lx2.46W x 1.59 H 174.0mmx62.5mmx40.5mm
Feature	OCP, OTP, OVP, SCP
Part Status	Last Time Buy
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Cable
Type	Constant Current
Depth	62.5mm
Termination Style	Wire Leads
Number of Outputs	1
Approval Agency	CB, CE, cURus, PSE, TUV
Efficiency	88%
Voltage - Isolation	3.75kV
Voltage - Input (Max)	295VAC
Voltage - Output 1	20V
Voltage - Input (Min)	90VAC
Output Current	4.8A
Output Power	96W
Voltage - Output	13V~20V
Topology	AC DC Converter
Current - Output 1	4.8A
Max Output Power	60W
Max Input Current	800mA
Height	40.386mm
RoHS Status	ROHS3 Compliant
Ratings	IP66
