95000-003TRLF

new-10%

Manufacturer part number:95000-003TRLF

Manufacturer:Amphenol ICC (FCI)

Description:Conn Wire to Board HDR 3 POS 2mm Solder RA SMD T/R

Case Package:SOT-23

Datasheet:95000-003TRLF Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Contact Material	Copper Alloy
Contact Plating	GXT, Gold
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Contact Shape	Square
Insulation Material	Thermoplastic
Housing Material	Thermoplastic
Packaging	Tape & Reel (TR)
Series	Minitek®
Feature	Board Guide, Keying Slot
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	3
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
Color	Cream
Number of Rows	1
Voltage - Rated	200V AC/DC
Fastening Type	Latch Holder
Contact Finish - Mating	Gold, GXT™
Contact Type	Male Pin
Current Rating (Amps)	2A AC/DC
Pitch	2mm
Orientation	Right Angle
Depth	10.77mm
Insulation Height	0.118 3.00mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Pitch - Mating	0.079 2.00mm
Insulation Color	Cream
Shrouding	Shrouded - 1 Wall
Number of Contacts	3
Contact Finish - Post	Tin
Contact Length - Mating	0.157 4.00mm
Housing Color	Cream
Mating Post Length	4mm
Length	6mm
Contact Finish Thickness - Mating	8.00μin 0.203μm
Contact Finish Thickness - Post	78.7μin 2.00μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Lead Free	Lead Free
